API Calls in IPA causing innerElementCountThreshold error

, ,

For API calls that return a large result set, you may encounter the message “Error while executing Web Service activity javax.xml.ws.soap.SOAPFaultException: reach the innerElementCountThreshold:50000”.  To resolve this issue, add a JVM command to allow a larger threshold.



Launch the Landmark Grid.  Click on the “configuration” icon.



Click “Applications”

Select your Landmark application



Click “Edit Properties”



Expand “Node Properties” under “Grid Defined Properties”



Click the link to Append another entry



Add the property “-Dorg.apache.cxf.stax.maxChildElements=<an appropriate # for your organization>”

Click “Update Property”

Be sure to save the Grid changes!!

Restart the server



Clear out the WAS temporary directories and cached files

, ,

If the IBM WebSphere Application Server deployment manager, node agent, or application server will not start, you can try clearing out the temporary directories and cached files.  Here are the steps to complete this procedure:

  1. Stop the deployment manager, node agent, and application server
  2. Back up the existing configurations
    1. Open a command line window as admin
    2. Navigate to PROFILE_ROOT\bin (i.e. D:\IBM\WebSphere\AppServer\profiles\profile1\bin)
    3. Run the command “backupConfig <backup file>”
    4. Repeat this backup step for every profile (Dmgr, AppSrv01, etc)
  3. Rename or archive the following directories
    1. PROFILE_ROOT/wstemp
    2. PROFILE_ROOT/temp
    3. PROFILE_ROOT/config/temp
    4. Repeat this step for every profile
    5. These folders will be recreated when the servers are restarted
  4. Delete the javasharedresources directory located at C:\Windows\System32\config\systemprofile\AppData\Local\javasharedresources
  5. Initialize the OSGI configuration and clear the OSGI cache
    1. Open a command line window as admin
    2. Navigate to PROFILE_ROOT/bin
    3. Run command “osgiCfgInit”
    4. Run command “clearClassCache”
    5. Repeat this step for every profile
  6. Start the deployment manager, node agent, and application servers

IPA Error – No More Data to Read from Socket

, ,

Prior to Landmark version 11.0.29, IPA had trouble recovering gracefully from a loss in data connection.  When IPA loses connection with the database, it can sometimes throw this exception in the Work Unit logs:

To recover from this issue, you will need to restart the LPA node in Landmark grid, or restart the Landmark server.  After that, upgrade Landmark to a more stable version at the earliest convenience.











Landmark error security.authen.os_account_not_configured

, ,

The error “security.authen.os_account_not_configured” in Landmark will present itself when attempting to open Landmark web pages.  There will be a 500 service error, and the security_authen.log will throw an exception similar to “: SecurityEventHandler #34 got exception.

1617884962 – L(2) : security.authen.os_account_not_configured”.

In this case, the resolution is to open the Landmark command line utility as the install user, and run the command secadm provision os -C -o -a.

Security_authen.log

Sat Sep 25 12:29:59.250 PDT 2021 – default-1617884962 – L(2) : security.authen.os_account_not_configured

Sat Sep 25 12:29:59.250 PDT 2021 – default-1617884962 – L(2) : SecurityEventHandler #34 got exception.

1617884962 – L(2) : security.authen.os_account_not_configured

Stack Trace :

com.lawson.security.authen.SecurityAuthenException: 1617884962 – L(2) : security.authen.os_account_not_configured

at com.lawson.security.authen.LawsonOSAuthenticatorImpl.getPrimordialContext(LawsonOSAuthenticatorImpl.java:206)

at com.lawson.security.authen.LawsonOSAuthenticatorImpl.getPrimordialContext(LawsonOSAuthenticatorImpl.java:58)

at com.lawson.security.server.SecurityEventHandler.getSecurityContextForEvent(SecurityEventHandler.java:376)

at com.lawson.security.server.SecurityEventHandler.processEvent(SecurityEventHandler.java:350)

at com.lawson.security.server.SecurityEventHandler.run(SecurityEventHandler.java:228)















secadm provision os -C -o -a













How to remove related forms for a custom Lawson portal Form

, ,

In Lawson you may be creating a custom ESS form that you don’t want users to be able to get to (assuming you removed the search button).



Example of this below:

Open design studio by going to https://yourcompany.domain/lawson/studio

To remove these related forms, edit the custom form in design studio and remove transfers id in source:

Save the now custom form, make sure it is set to default in logan or is accessible via a bookmark direct URL.



Clear your IOS Cache and test to make sure the related button is now gone.



Good luck!

Lawson Business Intelligence Smart Notes – Failed to obtain DB connection from data source

, ,

LBI Smart Notes not working (even intermittently) and the SystemOut log is spamming the error below?

Failed to obtain DB connection from data source ‘SNDB’: java.sql.SQLException: Could not retrieve datasource via JNDI url ‘java:comp/env/jdbc/LawsonSN’



Below is an easy fix for this as this is typically caused by differing versions of java.



First login to your LBI server and locate the InforLawsonBI Install directory typically found on the secondary drive (D drive in our case)

Go to file path:

..\InforLawsonBI\SmartNotification\Smart Notification.ear\lsnwar<Insert version>.war\WEB-INF\classes

Locate and open the quartz.properties file with Notepad or a text editor of your choice.

Edit the line shown below:

Change it to the following:

Save and reboot the LBI server or restart the IBM Webservices.

That’s it!

Infor Lawson cannot load because the Profile service returned an error: Error occurred while accessing user data

, ,

If one of your users in Lawson Portal or Mingle is receiving this error (or similar), a Lawson Security administrator will have to follow the steps below.

  1. Login to Lawson Administrator Tool
  2. Go to Use Management > User Maintenance
  3. Query the user who is having the issue.
  4. Right-click on their record and choose ‘Edit Lawson Environment Information’.
  5. Make sure the user has a data area set. Edit >> Change after changing.
    1. Alternatively, if the data area is already set, select Edit >> Change. Reminder, if you are using ISS, hit the save icon. (You do not need to actually add or change anything on this form/screen.) This creates the R_USER record in the GEN database.
  6. In Lawson portal (or mingle, selecting the globe icon), if you’re a portal admin, you should see an option to Clear IOS Cache.
  7. Have the user that was encountering the error close all of their web browsers Internet Explorer (IE), Chrome, Edge, etc and then open a new web browser session and log in again.

Note: LSF 9 ONLY – LAUA users: If the user has the attribute CheckLS=No, the user may also need an LAUA Security Class assigned to their Operating System account via LAUA.



Good luck!
