Generating a simple approval level report from the Landmark database

Lawson natively supports requisitions and a hierarchy requisition approval system within organizations. Some use both the approval strings found in RQ02 and setup filters within Lawson Rich Client (An application in Lawson Landmark). More info on this can be found in another one of our articles titled: “A Brief Overview into the Lawson Requisition and Approval Process”


To generate a database dump of all approvers and their levels using my method, you’ll need read access rights to the LSL, IPA, and GEN databases and must be using SQL.


    1. Login to your TEST or PROD database application.
    2. Create a new query window and paste the below SQL code in, one is a screenshot to show syntax highlights and the other is the raw code for your convenience.

      Run the query and your results should show as so:
    3. Copy and paste with headers into Excel to filter down the data or edit the query.

I’ve included an Active Status to show which locations are active or inactive. This can be changed in RQ01 per company and location.

Feel free to optimize the query to your likings if you see any inefficiencies. Remember, this is only for approval levels on the landmark side, not the RQ02 strings themselves.

Landmark Application Configuration Overview

The Landmark Configuration Console allows you to effect system-wide changes with no downtime for your users.  You can personalize your Landmark applications in a multitude of ways:

  • Add custom fields
  • Move fields or remove them from forms
  • Set fields to required
  • Modify list columns (add/remove/rearrange)
  • Create new
    • User interfaces (pages, lists, etc)
    • Business classes (data, objects, etc)
  • Security
    • Use the Security Configuration tool to modify security classes, rules, and roles
  • Web Services
    • External systems communication with Landmark business classes using SOAP, HTTP, WSDL, or REST

The Infor-delivered role what will allow users to access Configuration Console is GlobalUIConfigAccess_ST.  The role that will allow users to access Security Configuration is SecurityConfigAccess_ST.

Get Business Class and Field Names for Landmark Applications

When setting up Landmark queries for IPA or Spreadsheet Designer, it helps to know which business class and field you are working with.  You can get these values in any Landmark application form (web-based or in Rich Client) by typing ctrl+shift and clicking on the field.

Landmark Security Access

To maintain Landmark Security (classes and roles), in the Gen environment in Rich Client, go to Start > Configure > Security.  If you don’t see the Security or Configure, you will need to have your Security Administrator give you access to it.  The Infor delivered role for this is “ConfigConsoleSecurityadmin_ST”.  Have that role added to your account and wait about 30 minutes for the sync to complete.

Setting up PGP Encryption in Landmark

There may be multiple applications for PGP encryption keys at your organization.  It is very simple to create and use the keys using the secadm tool on your Landmark server.

  1. On your Landmark server, open a command line tool and set your environment
  2. Type command secadm -m, then enter the security utilities password if prompted
  3. Select option “Key management” (in later versions, this is found under Service Management)
  4. Choose option “Generate PGP Key Pair for a service”
  5. Enter the service (such as SSOPV2)
  6. Open the Service in Rich Client and validate that the PGPPrivateKey and PGPPublicKey properties were added

How to Resolve Workunits Sitting in Ready Status

Problem: Workunits for Infor Process Automation are sitting in Ready Status and not processing.

1.  Via LmrkGrid (Grid Management), determine how many workunits may simultaneously process in your system. (see attached “DeterminingSimultaneous.docx”)

  1. Determine how many workunits are currently in a processing state.

NOTE:  Please refer to attachment “DeterminingSimultaneous.docx” for instructions on determining simultaneous processes.  In case you will need to engage support, you should screenshot this information to provide when you open the support incident.


– Command to count records in Ready Status:  dbcount <DATAAREA> -f Status=\”1\” PfiWorkunit

– Command to count records in Processing Status:  dbcount <DATAAREA> -f Status=\”2\” PfiWorkunit

– Command to count records in Completed Status:  dbcount <DATAAREA> -f Status=\”4\” PfiWorkunit


It is a good idea to monitor and take counts of these records periodically. Are the number of workunits in Ready status growing? Are the number of workunits in Completed status growing? Is the number of workunits in Processing status equal to the maximum number workunits that can simultaneously process?

NOTE: If the number of workunits in Ready Status is growing and the number of workunits in completed status is not, then either:

  1. You have workunits that processing for a very long time holding up the system; use the Grid Management UI to determine which workunits are processing so long and determine if those are stuck in a loop; or if they are just processing normally large jobs. Consider cancelling the long running workunits, and scheduling them to run in off business hours.
  2. If you are on Landmark 10.1.0.x, there was a bug in this version of Landmark that periodically caused Async to stop picking up new workunits. This issue was resolved by a re-write of Asnyc and LPA nodes in 10.1.1.x Landmark versions. If you are on Landmark 10.1.0.x you should restart the Async Node, and the IPA node.

NOTE: The workunits that were already queued to an LPA node will not automatically start back up;  the workunit polling frequency (default 30 minutes) will need to trigger before they are requeued to a new LPA node.

Troubleshooting: Rich Client workunit log too large to extract

Depending on the process run, Rich Client workunit logs can grow extremely large. So large in fact that you may not be able to extract the full log from the Landmark Rich Client.

If a workunit log grows too large you may not be able to extract the full log from the Landmark Rich Client,  in this case you can use the following command to extract the log from a Landmark Command Prompt.

What Is the Landmark Command Prompt?
The Landmark administrator will perform many tasks from a command prompt. When you are instructed to use a Landmark command prompt, you should be sure you are in the Landmark Environment that you want to use, and that all environment variables are set correctly.

Setting Environment Variables
Before you startBefore you perform this procedure, be sure that the /etc/lawson/environment/environmentName/ file contains the appropriate settings for environment variables.


Use this procedure to export the appropriate environment variables for your Landmark Environment before issuing commands from a Landmark command prompt.

To set the Landmark Environment variables

At a command prompt, type

. cv landmark-env-name

Where landmark-env-name is the name of the Landmark Environment.


dbexport -C -f “PfiWorkunit=####” -o . -n <dataarea> PfiWorkunit


dbexport -C -f “PfiWorkunit=7000” -o . -n prod PfiWorkunit

Adding a custom field to a form using Configuration Console

Find the name of the Form and the Business Class that you want to add the field to (Ctrl-Shift-Click on any field on the form)

Log into Rich Client and go to Start > Configure > Application (make sure that you have been granted access to Configuration Console)

Find your Business Class, and click “User Fields” under the class

Click the “blank paper” icon to add a new user field

Give your user field a meaningful name (no numbers or special characters allowed, and the field name must begin with an upper-case letter)

Next, go to configured forms and find the form name that you noted earlier

If this form has never been customized, you may need to click the blank paper icon to add it to the Configured Forms list

Once the form has been added as a configured form, click on the form name, then click “Configure”

Navigate to the location where you want to add the user field

Click the blank paper and select “User Field”

Configure the user field for the form

Click “Save” and verify that the user field is now on your screen

Rich Client Dev vs Prod Appearance

When using Infor Cloud, the landmark rich client looks the same in dev as it does in prod. How can I easily recognize the difference between them?

Mistakes can happen when you are frequently changing between a development and production environment. It is easier to tell the difference between the environments when the productlines are installed with different names (dev and prod for example). If your environments use the same names, you can change the appearance in the rich client to help make it more obvious which environment you are using. From the Rich Client, click Start – Settings. Then select a different Theme color for the dev productline (green for example) and add DEV to the Display Name field. The other productlines on the dev system can also be selected and changed to green. Each of the productlines on the prod system can be changed to another color while also changing the Display Name to include PROD.

How Can I Personalize a Form?

From the Landmark Rich Client, forms can be changed under Options – Personalize in the menu.  Fields on a form can be renamed or changed in color or style.  They can be hidden, marked as display only, or as required.  In this example, the field “Last Employment ID Assigned” is highlighted in bold red with a shortened name.   Once Personalize is selected, Form Personalization shows Actions and Fields at the top.  Actions will allow restrictions for a specific condition.  In this case, click on the “Last Employment ID Assigned” and then click Fields in the upper right.  Select the Label tab to change the style, color, and text.  Once the changes are made, the window is closed and the Form Personalization is Saved in the upper right.  The changes are then seen immediately without restarting the client.  To undo the changes, return to Options – Personalize in the menu, and click Reset in the upper right.
